Compact Radar-Speed Trailer
HK-VMSC-RST
The HANKUN-12 Speed Radar Trailer was designed for smaller residential streets, universities, and corporate campus type applications where speeding is a problem. While this radar speed trailer may be light in weight, it is built to the same tough industrial standards as its bigger brothers. Conveniently towed with a passenger vehicle or even a golf cart, the trailer can be easily repositioned throughout a community’s streets for maximum effectiveness.
This trailer mounted speed detector radar is accurate within one mile per hour, and easily read at a glance. The 12” high, full matrix LED characters can be seen from 750 feet to alert the driver of their speed. And optional violator alerts make your point clear to all.
This trailer mounted speed detector radar is accurate within one mile per hour, and easily read at a glance. The 12” high, full matrix LED characters can be seen from 750 feet to alert the driver of their speed. And optional violator alerts make your point clear to all.
Quantity:
Compact Radar-Speed Trailer by HANKUN – Precision Traffic Management for Every Environment
Engineered for versatility and performance, HANKUN’s Compact Radar-Speed Trailer sets the standard for portable traffic monitoring. As a leading manufacturer of Radar Speed Trailers, we deliver solutions that blend advanced radar technology, rugged portability, and customizable functionality to enhance driver awareness and reduce speeding in urban, suburban, and rural environments.
Key Features: Intelligent Design for Proactive Safety
1. Adaptive Speed Monitoring Technology
- High-Precision Radar: K-Band radar (24.15 GHz, FCC/CE compliant) detects vehicle speeds up to 1,000 ft (305m) away, supporting real-time feedback in mph/km/h.
- Dynamic LED Display:
- Oversized Panels: 12”–24” amber/full-color LED screens (2.5–3-digit display) with 20,000 cd/m² brightness, visible over Jersey barriers and in direct sunlight.
- Vandal-Resistant: Lexan® protective windows and anti-glare lenses ensure long-lasting clarity.
2. Portable & Rapid Deployment
- Compact Form Factor: Lightweight designs (380–650 lbs) with 8”–10” ST-rated tires, enabling 5–10-minute setup via heavy-duty hand winch and stabilizer jacks.
- Towing Flexibility: Universal hitches (2” ball, 2.5” pintle hook) fit cars, trucks, or trailers, ideal for portable radar trailers requiring frequent relocation.
3. Customizable Speed Control
- Adjustable Thresholds: Program speed limits (5–75 mph/km/h) with configurable alerts—flashing messages (“SLOW DOWN”) or dynamic graphics for exceedances.
- Regulatory Compliance: MUTCD (USA), TSRGD (UK), CE, and RoHS certified, with interchangeable speed sign placards for global use
Multi-Spec Models for Diverse Needs
Model 1: Compact 12 – Urban & Community Safety
- Use Case: School zones, residential streets, low-speed work areas.
- Dimensions:
- Transport: 52”W x 90”L x 48”H
- Deployed: 52”W x 48”L x 72”H (sign raised).
- Power: 80Ah marine battery (standard); 50W solar panel (optional for off-grid use).
- Display: 12” amber LED (2.5-digit, leading 1 for speeds ≥100).
Model 2: Heavy-Duty 18 – High-Traffic & Industrial Sites
- Use Case: Highways, construction zones, logistics centers.
- Dimensions:
- Transport: 60”W x 120”L x 54”H
- Deployed: 60”W x 60”L x 84”H (36” full-color LED display).
- Power: 2x 100Ah AGM batteries + 20A charger; 100W solar panel with MPPT controller (72-hour backup).
- Durability: IP65-rated steel enclosure, 10” heavy-duty tires, and wind resistance up to 40mph.
Model 3: Solar-Powered 24 – Remote & Eco-Conscious Projects
- Use Case: Rural roads, temporary traffic control, green initiatives.
- Dimensions: 48”W x 84”L x 42”H (compact for tight spaces).
- Power: 60Ah lithium battery + 80W solar panel (auto-charging, zero grid dependency).
- Eco-Features: 80% energy efficiency, sealed battery design, and 95% recyclable components.
Technical Excellence & Reliability
Power & Sustainability
- Hybrid Solutions: Solar-battery systems with auto-shutdown protection (prevents overcharging) and commercial power compatibility for permanent installations.
- Longevity: Powder-coated steel frames, rust-resistant undercoats, and replaceable bolt-on fenders ensure 10+ years of service in -25°C to +60°C environments.
Data & Control
- Integrated Data Logging: Track vehicle counts, speed statistics, and peak activity via optional GPS modem (cloud-compatible for real-time monitoring).
- User-Friendly Interface: Touchscreen controllers for instant settings adjustment (message programming, brightness, unit conversion).
Applications: Where Safety Meets Flexibility
- Law Enforcement: Monitor speed compliance and collect evidence for traffic enforcement.
- Construction Zones: Guide vehicles through temporary limits, protecting workers with flashing alerts.
- Schools & Communities: Deploy near crosswalks with smiley-face feedback to engage drivers and reduce child accident risks.
- Industrial Premises: Enforce low-speed limits (5–10 km/h) in airports, warehouses, and loading zones.
Why HANKUN Leads in Radar Speed Trailer Innovation?
- Customization: Tailor display size, power options, and towing hitches to project-specific requirements.
- Global Trust: Decades of expertise in manufacturing portable radar trailers compliant with international safety standards.
- Total Cost Efficiency: Low maintenance, energy-saving designs, and modular upgrades maximize ROI.
Technical Specifications (Standard)
| Category | Details |
|---|---|
| Display Technology | Amber LED (standard); full-color RGB (optional) |
| Speed Range | 0–999 mph/km/h (configurable in 1-unit increments) |
| Power Source | Solar panel (50W–100W) + battery (60Ah–200Ah) |
| Mounting | Trailer-hitched with adjustable stabilizer jacks |
| Weather Rating | IP65-rated for dust/water resistance; UV-resistant coatings |
| Control Options | Local touchscreen, remote Bluetooth, or cloud-based software |
Deploy with Confidence
HANKUN’s Compact Radar-Speed Trailer combines precision engineering with user-centric design, delivering a Radar Speed Trailer solution that adapts to any traffic challenge. Whether you need a portable radar trailer for temporary use or a permanent monitoring system, our customizable models ensure optimal safety, compliance, and efficiency.
Contact us today to discuss a tailored solution for your traffic management needs—engineered by experts, built for performance.
